Xilinx Zynq-7000 All Programmable SoC ZC702 Evaluation Kit
Product Description
The Zynq®-7000 AP SoC ZC702 Evaluation Kit includes all the basic components of hardware, design tools, IP, and pre-verified reference designs including a targeted design, enabling a complete embedded processing platform. The included pre-verified reference designs and industry-standard FPGA Mezzanine Connectors (FMC) allow scaling and customization with daughter cards.
Key Features & Benefits
- Optimized for quickly prototyping embedded applications using Zynq-7000 SoCs
- Hardware, design tools, IP, and pre-verified reference designs
- Demonstrates a embedded design, targeting video pipeline
- Advanced memory interface with 1GB DDR3 Component Memory
- Enabling serial connectivity with USB OTG, UART, IIC, CAN Bus
- Supports embedded processing with Dual ARM Cortex-A9 core processors
- Develop networking applications with 10-100-1000 Mbps Ethernet (GMII, RGMII and SGMII)
- Implement Video display applications with HDMI out
- Expand I/O with the FPGA Mezzanine Card (FMC) interface
Related Products
What's Included
- ZC702 evaluation board featuring the XC7Z020 CLG484 -1 AP SoC
- Full seat Vivado® Design Suite: Design Edition
- Node locked & Device-locked to the Zynq-7000 XC7Z020 SoC, with 1 year of updates and support
- Node locked & Device-locked to the Zynq-7000 XC7Z020 SoC, with 1 year of updates and support
- AMS 101 evaluation board
- Printed Quick Start Guide
- Targeted Reference Design showcases various embedded domain features and capabilities with a Linux-based video pipeline design
- Board Design Files (DxDesigner 2005, Allegro 16.3 – 16.5)
- Cables & Power Supply
Featured Documents
Key Features
Zynq-7000 XC7Z020 CLG484 -1
- ROHS compliant ZC702 kit including the XC7Z020-CLG484-1 AP SoC Power 12V wall adapter or ATX voltage and current measurement capability of supplies
Configuration
- Onboard configuration circuitry
- 16MB Quad SPI Flash
- SDIO Card Interface (boot)
- PC4 and 20 pin JTAG ports
Memory
- DDR3 Component Memory 1GB
- Support 32 data width
- 16MB Quad SPI Flash
- IIC - 1 KB EEPROM
Communication & Networking
- Gigabit Ethernet GMII, RGMII and SGMII
- USB OTG 1 (PS) - Host USB
- IIC Bus Headers/HUB (PS)
- 1 CAN with Wake on CAN (PS)
- USB UART (PS)
Video/ Display
- HDMI Video OUT
- 8X LEDs
Expansion Connectors
- FMC #1-LPC connector (0 GTX Transceiver, 68 single-ended or 34 differential user defined signals)
- FMC #2-LPC connector (0 GTX Transceiver, 68 single-ended or 34 differential user defined signals)
- IIC HUB/Expander
- Dual Pmod (8 I/O Shared with LED's)
- Single Pmod (4 I/O Shared with PJTAG)
Clocking
- 200MHz Fixed PL Oscillator (Differential LVDS)
- 156.25MHz (default) I2C Programmable Oscillator (Differential LVDS)
- 33.33MHz Fixed PS System Oscillator (Single-Ended CMOS)
Control & I/O
- 3 User Push Buttons
- 2 User Switches
- 8 User LEDs
Power
- 12V wall adapter or ATX
- Voltage and Current measurement capability of supplies
Analog
- XADC header
Highlighted Partner Bill of Materials (BOM)
| Provider Name | Product Category | Item |
|---|---|---|
| Analog Devices Inc | Component | ADV7511 HDMI transmitter |
| SiTime | Component | SiT9102AI-243N25E200.00000 SiT8102AN-23-25E-12.00000 SiT8103AC-23-18E-33.33333 |
| Xilinx | Power Management design examples | Power management vendor products and tools |
Key Features
Download the AMS Evaluator and your design files at the Xilinx support site.
- Analog evaluation card connects to XADC header
- Evaluates XADC 12-bit, 17-channel, 1Msps dual ADCs and Analog Mixed Signal technology
- Pins and BNC mini grabbers allow for external analog input signals
- On-board 16-bit dual DAC for analog test signals
- Reference designs allow sine wave or DC test signals
- AMS101 Evaluation card pairs with free AMS Evaluator tool for analyzing analog data, internal temperature and voltage measurements, and saving data to a .csv file
Featured Documents
Xilinx Support
Included in this Kit
Design tools
| Name | Description | License Type |
| Vivado Design Suite: Design Edition | The Xilinx Vivado® Design Suite is a revolutionary IP and System Centric design environment built from the ground up to accelerate the design for all programmable devices. | Node locked & Device-locked to the Zynq-7000 XC7Z020 SoC, with 1 year of updates |
